Specifications

Specifications

  • Vessel Name: OSV RELUME
  • Owner: International Foundation For Aids To Navigation (IFAN)
  • Operators: MENAS Marine Services Ltd (MMSL)
  • Builder: Damen Shipyards, Vlissingen, Holland
  • Year Completed: 2004
  • Flag: Bahamas.
  • Port of Registration: Nassau
  • Classification: Lloyd’s Register of Shipping LMC 100A1, UMS, DP(AA), NAV, IBS. SPS Code compliant
  • Length Overall: 82.60 metres
  • Breadth Moulded: 16.50 metres
  • Depth Moulded to Main Deck: 6.80 metres
  • Design Draft: 4.00 metres
  • Max Draft: 4.50 metres
  • Deadweight Max: 1500 T
  • GRT: 3526
  • NRT: 1057

Fuel Consumption:

  • Speed: 13m3 per day @ 11 knots / 15m3 per day @ 13 knots
  • Class 2 DP Operations: 3 - 6m3 per day

Capabilities:

  • Service Speed: 0-13 knots
  • Diesel Generating Plant: 2 x 8L20 8-cylinder 900 rpm Wartsila Diesel Engines of 1317 KW (1625 kVa) each; 2 x 6L20 6-cylinder 900 rpm Wartsila Diesel Engines of 988 KW (1250kVa) each; 1 Caterpillar Emergency Diesel Alternator of 145 KW capacity; 2 x 4L20 4-cylinder 900 rpm Wartsila Diesel Engines of 420 KW capacity each for Crane and Deck Power
  • Propulsion Systems: 2 x Rolls Royce (Aquamaster) Azimuth units of 1500 KW each, 2 x Rolls Royce (Kamewa) Bow Tunnel Thruster units of 700 KW each

Tank Capacities:

  • Fuel Oil: 540m3
  • Freshwater/ballast: 835m3
  • Potable Water: 146m3

DP Dynamic Positioning System:

  • Kongsberg Simrad K-POS system to Lloyd’s DP (AA) standard; Kongsberg Simrad HiPAP 501 HPR; 3 x DGPS (IALA, C-Nav 3050 & Veripos ULTRA); 2 x Wind Sensors Young; 2 x MRU; 3 x Gyro; Tautwire Bandak LTW MK14B System; Kongsberg RADius 1000; FMEA, DP Capability Analysis and Annual Trials - Petrofac, Aberdeen.

Bridge System and Communications:

  • Litton Sperry System to Lloyd’s NAV1; SatMarin KU Band Unlimited Azimuth Transmit/Receive System; Fleet 77 and Sat C fully integrated communications system; IBS; ECDIS; Kongsberg Simrad installation, EA 600 Single Beam with EM 3000 multi-beam; Kongsberg Neptune, C-floor, Triton and Poseidon; 1 x Sonar CH37, Furuno.

Craneage facilities:

  • 1 x 25-tonne crane @ 12m (12 tonnes @ 20m)- Active heave compensated - Knuckle boom Main Crane, starboard-mounted. Subsea rated to 1000 metres 1 x 13-tonne crane - General Purpose Telescopic Crane, port sidemounted

Working Deck Layout:

  • Deck Area: Approx 500m3
  • Max Deck Loading: 5 tonne / m2
  • Deck area: Container locator points across deck

Accommodation:

  • 10 x single berth Officers cabins
  • 28 x twin berth cabins
  • 21 x twin berth cabins available for client use
  • 2 x Client Offices, Operations room, Conference Room
  • Total POB: 66
